APPENDIX A - CONTINUED

COMMUNICATIONS CHARACTERISTICS

INTERFACE:

RS 232 serial
Centronics-compatible parallel

HANDSHAKING PROTOCOLS:

X-On, X-Off, ETX/Acknowledge
Data Terminal Ready

COMMUNICATIONS RATE:

110-19.2Kbaud

BUFFER:

16K character FIFO on both serial and parallel

interfaces

GENERAL CHARACTERISTICS

CASE:

High impact injection-molded thermoplastic

DISPLAY:

4-digit LED

RIBBON:

Cartridge
3/4 "x25 yards continuous loop

MICROPROCESSOR:

Intel 8085

SIZE:

7.8"Hx24.5"Wxl6"D

WEIGHT:

35 lbs./16 Kilos

ELECTRICAL REQUIREMENTS:

110/220VAC -50/60 Hz

ENVIRONMENTAL:

Operating

Temperature:

5 C - 40 C(41 F - 104 F)

Humidity:

15 to 90%(no condensation)

Shock:

Og

Vibration:

1/2 g maximum with a frequency of 10 to 60

Hz

Altitude:

3048 meters (10,000 feet) above MSL,

maximum. Derate maximum temperature
linearly from 40 C at 1523 meters to 25 C at
3048 meters.

Non-Operatingfln Shipping Container)

Temperature:

-30 C to +70 C (-24 F to +158 F)

Relative Humidity:

5% to 95% (no condensation)

Shock:

30 g maximum (1/2 sinewave with a duration
of 11 milliseconds along any three
perpendicular axes).

Vibration:

2 g maximum with frequency of 10 to 300 Hz
6 minute linear sweep.

Altitude:

15,240 meters (50,000 ft.) above MSL,

maximum.

AGENCY COMPLIANCES

Safety:

UL1950
CSA C22.2 No. 950-M89
ШС950

Electromagnetic Interference:

FCC Class A
EN55022 Class A
VDEClassB

A -2
