APPENDIX H - CONTINUED
ESC = N1 N2 DC4 p al a2 pi pi... pll Download characters
This command is used to download up to 256 consecutive characters into
Random Access Memory. The user can overlay the entire character set or any
portion of the character set; however, each download must be contiguous from
die beginning character. Download characters are defined in terms of a 9 x 12
matrix; however, the 12th column is assumed to be blank.
The variables “nl” and “n2” are used to determine the numb» of bytes to be
downloaded. In order to calculate values for “nl” and “n2”, the total number of
bytes must first be determined by the following formula:
total bytes = (number of characters to be downloaded x 13) +2
If the total bytes to be downloaded is less than 256, then “nl” is equal to the total
bytes and “n2” is equal to 0. If the total bytes is greater than or equal to 256,
divided the total bytes by 256. “nl” is equal to the remainder and “n2” is equal to
the integer quotient. For example:
To download 14 characters:
total bytes = (14 x 13) +2
total bytes = 184
Since total bytes is less than 256;
nl = 184
n2 = 0
To download 38 characters:
total bytes = (38 x 13) +2
total bytes = 496
Since total bytes is greater than or equal to 256;
total bytes = 496/256
nl = 240
n2 = 1
After determining values for “nl” and “n2” always enter a DC4. DC4 is the
value used to identify the printer.
The variable “p” is the decimal value of the first character to be downloaded. The
starting
character is determined by the programmer and can begm at any point;
however, all characters must be contiguous from the start character. Values for
“p” can range from 0 to 256.
H-9
