APPENDIX A SPECIFICATIONS

PRINT AND FORMAT

CHARACTERISTICS

PRINTHEAD;

18-wire ballistic-type matrix head

PRINT MODES:

9x7 matrix in draft mode at 400 CPS
9X9 matrix in draft mode at 325 CPS
9X15 matrix m memo mode at 180 CPS

18X20 matrix in NLQ mode at 120 CPS
18X24 matrix in NLQ mode at 100 CPS

High resolution dot addressable graphics

CHARACTER PITCH/MAXIMUM LINE

LENGTH:

5 cpi / 66 columns
6 cpi / 79 columns
6.6 cpi / 87 columns
7.5 cpi / 99 columns
8.5 cpi / 109 columns
8.75 cpi /115 columns

10 cpi / 132 columns
12 cpi / 158 columns
13.2 cpi / 175 columns
15 cpi / 198 columns
16.5 cpi / 219 columns
17.1 cpi /231 columns *

VERTICAL PITCH:

6 or 8 lines per inch or programmable in half
dot increments (up to 1 Vi inches)

CHARACTER SETS:

U.S. ASCn
U.K. ASCn
German
Spanish n

Norwegian/Danish

Spanish I

IBM PC
French
Swedish/Finnish
Greek

* Available with Proprinter option only

HORIZONTAL TABS:

Up to 32

VERTICAL TABS:

Up to 32

FORM LENGTH:

Up to 217 lines

MULTIPART FORM THICKNESS;

Up to 6 parts, adjustable; .021" maximum

CARRIAGE SLEW RATE:

40"/second maximum

TYPE FONTS:

Draft (9X7) - 10,12,15 and 16 CPI
Draft (9X9) - 10,12,15 and 16 CPI
Memo - 10 and 12 CPI
NLQ - Courier 10 CPI
NLQ - Helvetica 12 CPI
OCR A
OCRB

Elite 12

COLUMNS:

Up to 217

FORM WIDTH:

3"-15"

PAPER FEED;

Tractor for continuous forms (bottom or firont
feed)

PAPER SLEW RATE:

15 inches per second

ADDITIONAL FEATURES:

Perforation skipover
Paper out indicator
Line/local power up selection
Top of form
Carriage jam detection

A -1
