FIFO not full

FIFO full

DSTR

\J

BUSY F

ACK

DSTR

\J

]__ BUSY ________ P

IT

ACK

Figure 2.2 Handshake on ACK

When Feature 59 is set to 1, the last character to cause BUSY to go high is
acknowledged (see Figure 2.3). In this case the host must honor BUSY.

FIFO not full

FIFO full

DSTR

~u

DSTR

BUSY

J

L

BUSY

ACK

M

ACK

IT

Figure 2.3 Handshake on BUSY

2.5.25

Feature 61 - EIGHTH BIT ENABLE

When Feature 61 is set to 1, the printer will process the eighth bit when
communicating with an 8-bit device. When Feature 61 is set to 0, the printer will
ignore the eighth bit.

2.5.26

Feature 63 - ETX/ACKNOWLEDGE HANDSHAKING

When communicating over the serial interface the operator may set Feature 63 to
enable an ETX/ACKNOWLDGE handshaking. When Feature 63 is set to 1,
handshaking wiQ occur as follows: The host will end each series of data sent to
the printer with ETX. When the printer detects ETX in the First-In First-Out
buffer, it sends acknowledge to the host.

2-20
