Section 1.7- SHEET METAL
Parts List for Exploded View of Sheet Metal
ITEM QTY
DESCRIPTION
ITEM
QTY
DESCRIPTION
1
1
Engine-Generator Divider Plate
26
1
Grounding Strap
2
1
Engine Upper Wrapper
27
1
Fuel Pump
3
1
Rubber Seal
28
2
Barbed 90* Fitting
4
1
Base Housing Wrapper
29
3
1/4”-20 Hex Nut
5
26
M5 Screw
30
3
1/4” Lockwasher
6
2
Customer Mounting Ralls
31
1
Starter Contactor
7
4
M8 Lockwasher
32
1
Starter Contactor Insulator Boot
8
4
M8-1.25 Capscrew
33
1
Oil Filter Opening Seal
9
5
M8-1.25 Capscrew
34
1
Seal Retainer
10
7
M6 Lockwasher
35
4
M8 Flatwasher
12
1
Spark Arrestor
36
1
Fuel Line
13
1
Exhaust Clamp
37
2
Hose Clamp
14
1
3/8"-16 Capscrew
38
1
Snap Bushing
15
1
3/8” Lockwasher
39
7
Lockwasher
16
1
3/8” Hex NHut
40
1
No. 8 Hex Nut
17
1
Air Outlet Deflector
41
1
No. 8 Hex Nut
18
1
Exhaust Muffler
42
2
M6-1.00 Capscrew
19
1
Lower Fan Housing
Carburetor Baffle SKlrt
44
1
Lockwasher
20
1
45
1
Grounding Strap
21
1
Rocker Cover Cover
47
1
Muffler Heat Shield
22
1
Spark Plug Side Skirt
48
1
Muffler Hanger Bracket
23
1
Belly Pan
49
1
Muffler Lower Insulation
24
25
1
1
Frame
Grounding Strap
50
1
Muffler Upper Insulation
Page 1.7-2
