Section 7,2- ENGINE DC CONTROL SYSTEM

Test 8- Check Power Supply to

Starter Motor (Continued)

RESULTS:
1. If power supply is good and engine cranks, stop

tests.
2. if power supply Is good but engine does NOT

crank, replace the Starter.

3. If power supply Is bad, go on to Test 9.

Test 9- Check Wire 56 Power to

Starter Contactor

DISCUSSION:

When the Start-Run-Stop switch is set to

"START", the Engine Controlier circuit board must

react by delivering battery voltage to the Starter

Contactor coil, via Wire 56. Without this battery

voitage, the Contactor wiii not energize and battery

output wiii not be deiivered to the Starter Motor.

The engine wiii not crank.

TEST PROCEDURE:

1. Set a VOM to read battery voitage (12 VDC).

2. Connect the meter test leads across the Wire 56

starter contactor terminal and frame ground.

3. Set the Start-Run-Stop switch to "START". The

meter should indicate battery voitage.

RESULTS:
1. No power to Wire 56 terminal, go to Test 10.

2. If power to Starter Contactor is good, go to Test

11

.

Test 10- Check Engine Controlier

Board Power Supply

DISCUSSION:

Fused battery voltage is delivered to the Engine

Controller circuit board via Wire 15. If this power

(12 VDC) Is not available to the board, cranking and

startup will not be possible.

This test will determine if battery voitage is avaii-

abie to the circuit board for its operation.

TEST PROCEDURE:

Set a VOM to read battery voitage (12 VDC).

Connect one VOM test iead to the Wire 15 terminal

on the Engine Controller circuit board. Connect the

other test lead to frame ground. The meter should

indicate battery voltage.

RESULTS:

1. If battery voltage is NOT indicated, check Wire

15 between the 15 amp fuse and the Engine Con-

troiier board. Repair, reconnect or replace the wire

as needed.

2. If 12 VDC was indicated, go to Test 12.

Page 7.2-8
