10-13
Chapter 10: OPERATION
3.2. Remote Microphone Operation Example
The emergency mode can not only be activated and restored from the connected fire alarm system, but also
from any Remote Microphone (RM-200SA or RM-200SF) set for emergency/general-purpose operation.
Here, the settings of the Fireman's Microphone RM-200SF installed on GF of Building A are used as an
example to explain the flow from emergency mode activation to its restoration.
[Setting Contents of Fireman's Microphone]
FIREMAN'S MICROPHONE
RM-200SF
Key Setting Function
RM-200SF
1
2
3
4
5
1
2
3
4
5
Emergency Broadcast Pattern
Start
Emergency Sequence Phase Shift
All-Zone Call
Press-to-Talk
Emergency Reset
(Reset message)
Activates emergency mode and recalls emergency sequence
patterns.
[Pattern contents]
Phase 1: Alert message; all zones; 5 minutes
Phase 2: Evacuation message; all zones; continuous
Shifts the phase of the sequence pattern currently being
broadcast to the next phase.
Selects all zones.
Makes microphone announcements.
Broadcast is restored from emergency to normal
(general-purpose) broadcast mode after Restoration message
announcement completion.
For instructions on assigning functions to function keys, see the separate Setting Software Instructions,
"Event Settings."
