Mode Remarks
Output channel
CH1 (main display) CH2 (subdisplay)
SEGMENT CHECK Number of edges can be
checked during measure-
ment.
MODE
(Measurement mode) NORMAL, P-P, PEAK,
and BOTTOM are avail-
able.
CALIBRATION Segment selectors X and
Y can be calibrated.
DISPLAY
(Switching items on
subdisplay) For items that can be
displayed, see P.89.
OFFSET
PROGRAM
(Storing and retrieving
program)
ZERO
HOLD Use PRM to use HOLD
for CH1 and CH2.
Page
PRM
PRM
MODE
SET
FNC
FNC
CAL
CAL
DISP
DISP
OFS FNC
FNC
PROG
HOLD
P.35
P.40
P.41
P.43
P.43
P.45
P.20
P.20
APPENDIX E Quick Reference Table
