51
CHAPTER 4 Functions and Controls
[COMMAND] List Function Command Description
Specifying segment SS Specifies segment check ON
check SR Specifies segment check OFF
Nn Specifies the number of
segments ("n") for segment check
Specifying D Specifies DIA
measurement segment E Specifies EDGE1
F Specifies EDGE2
Sm, n Specifies values ("m" and "n)
for SEG (m, n) (m < n)
Setting number of A0 Sets 1
measurements A1 Sets 2
for averaging A2 Sets 4
A3 Sets 8
A4 Sets 16
A5 Sets 32
A6 Sets 64
A7 Sets 128
A8 Sets 256
A9 Sets 512
AA Sets 1024
Setting averaging BS Sets simple (SIMPLE) averaging
method BM Sets sequential (MODE)
averaging (Valid only when the
number of measurements is set
to any of 16, 32, 64, 128, 256,
512 and 1,024)
Setting program to LDn Loads program No. "n"
be loaded
Setting program to SVn Saves current settings into be saved
program No. "n"
Locking panel key RS Locks panel key operation
operation RR Cancels locking of panel key
operation
Setting UM Sets "mm"
measurement unit UI Sets "inch"
Setting channel to J1 Sets CH1 only
which HOLD J2 Sets both CH1 and CH2
function is applied
Setting AUTO ZERO ZS Sets AUTO ZERO function
function ZR Cancels AUTO ZERO function
Setting HOLD HS Sets HOLD function
function HR Cancels HOLD function
• When the command for locking of panel key operation is entered, any
change of settings cannot be performed using the panel keys. At this time,
setting indicator LOCK lights.
• If there is an error in the format, all the commands in that format are
disregarded.
• Only one command for setting various functions can be entered for one
format.
Commands for setting functions
