71
Pin No. Signal Function
17 REN Allows the controller to remotely enable or
disable devices on the line.
18 GND (DAV) Ground for control bus
19 GND (NRFD) Ground for control bus
20 GND (NDAC) Ground for control bus
21 GND (IFC) Ground for control bus
22 GND (SRQ) Ground for control bus
23 GND (ATN) Ground for control bus
24 Logic GND Signal ground
Interface Functions The interface bus functions of the LS controller are as follows:
Code Functions
SH1 All transmission-handshaking functions Provided
AH1 All reception-handshaking functions Provided
T5 Basic talker function Provided
Serial polling function Provided
Talk only function Provided
Function that releases a device from being a talker Provided
as soon as the device is specified as a listener
L4 Basic listener function Provided
Function that releases a device from being a listener Provided
as soon as the device is specified as a talker
SR1 All service-request functions Provided
RL0 Function that allows the controller to remotely Not
enable or disable devices on the line provided
PP0 Parallel polling function Not provided
DC1 All device-clear functions Provided
DT1 All device-trigger functions Provided
C0 Controller function Not provided
E2 3-state driver Provided
CHAPTER 6 Optional Interface Boards
Initial Setting
Be sure to turn OFF the power of the LS controller, then set these switches.
Since the GP-IB allows up to 15 devices to be interconnected, an address
must be assigned to each device. To assign the address, use the DIP
switches on the back panel of the LS controller. (See the figure below). The
talk only mode or delimiter can also be set using these switches.
1 2
ON
5 6 7 8
C R L F
4
16 8 4 1 2
Use these switches to set address
Use this switch to set talk only mode
Use these switches to set delimiter
OFF
Set this DIP switch to ON to enable "L ". (To enable
both "C " and "L " or only "C ", set this switch to OFF.)
F R
F
R
R
F
C
+
L
ON
