APPENDIX C
S
PECIFICATIONS
TTL voltage level, negative logic
NPN open-collector: 40 mA max. (30 V max.)
Display
Terminal block
I/O
Interface
port
36-pin connector
I/O
RS-232C
Non-voltage input (contact/solid state)
Controller
Type Multi-functional (for connecting 2 scanning heads)
Model LS-3100(W) [LS-3100D(W)]
Main display: 7-segment green LED (8 digits)
Measured value Subdisplay: 16 character x 2 line LCD
(Backlight color: yellow-green)
Minimum display unit 0.0001 mm (0.00001 inches)
Display range -999.9999 to 9999.9999
Measuring range mm/inch selectable
Target position indicator Green LED (7 levels)
Comparator output indicator Green LED x 3 (HI/GO/LO)
Laser emission indicator Green LED x 2 (HEAD 1/HEAD 2)
Hold synchronous
LASER REMOTE
PROGRAM SELECT
(Program Nos. 1 to 5)
Analog voltage ±6 V, Output impedance: 0 Ω
Control output Relay output: SPST-NO contact x 3, 250 VAC, 2 A (resistive load)
Hold synchronous
AUTO ZERO SET/RESET
PROGRAM SELECT
(Program Nos. 1 to 5)
7-level
3-level
Measurement data output and control input
(baud rate: 75 to 19200 bps selectable)
GP-IB 1. Measurement data output and control input
BCD 1. Measurement data output (8 digits)
Power supply 85 to 264 VAC, 50/60 Hz
Power consumption 65 VA max.
Ambient temperature 0 to +40°C (32 to 104°F), No freezing
Relative humidity 35 to 85%, No condensation
Weight Approx. 4.6 kg
1. Available as an option.
