CHAPTER 4 Functions and Controls
Output of Measurement Data Specifies the output method of the processed measurements which are
displayed on the main display (CH1) and sub-display (CH2), and outputs
them according to the specified method.
Input format: [COMMAND] CR
Function Command Description
Specifying data X0 Outputs measurement data of CH1 once
output method X1 Outputs measurement data of CH1
of data outputting continuously
X2 Outputs measurement data of CH2 once
X3 Outputs measurement data of CH2
continuously
X4 Outputs measurement data of CH1 and
then that of CH2 once
X5 Outputs measurement data of CH1 and
CH2 alternately and continuously
X6 Stops continuous output
Output data format:
• At normal measurement
Measurement in "mm"
Measurement in "inch"
When there is no 1st, 2nd and 3rd data, signal corresponding to blank
( SPACE ) is output, allowing these digits to be displayed as blank.
• At erroneous measurement
Measurement in "mm" or "inch"
Measurement data processed on the basis of the current settings is output,
according to the specified command, 10 ms max. after the command has
been received.
When "X4" or "X5" command is entered, the values of CH1 and CH2 ob-
tained when the command is received by the LS are output in order of CH1
and CH2.
1st data 2nd data 3rd data 4th data 5th data 6th data 7th data 8th data 9th data 10th data
C R
3 '-' or 10 digit 2 10 digit 1 10 digit 0 10 digit -1 10 digit Decimal point -2 10 digit -3 10 digit -4 10 digit
1st data 2nd data 3rd data 4th data 5th data 6th data 7th data 8th data 9th data 10th data
C R
2 '-' or 10 digit 1 10 digit 3 10 digit -1 10 digit -2 10 digit Decimal point -3 10 digit -4 10 digit -5 10 digit
1st data 2nd data 3rd data 4th data 5th data 6th data 7th data 8th data 9th data 10th data
C R - - - - - - - - -
