85
Temperature
Characteristics
(Typical) When a rod 10 mm in diameter is measured at the center of the measuring
area [reference temperature: 20°C (68°F)].
LS-3032
Temperature 0°C (32°F) 10°C (50°F) 20°C (68°F) 30°C (86°F) 40°C (104°F)
Drift +2.2 µm +1.1 µm 0 -1.4 µm -3.2 µm
LS-3033*
Temperature 0°C (32°F) 10°C (50°F) 20°C (68°F) 30°C (86°F) 40°C (104°F)
Drift +2.0 µm +0.8 µm 0 -1.0 µm -2.2 µm
LS-3034
Temperature 0°C (32°F) 10°C (50°F) 20°C (68°F) 30°C (86°F) 40°C (104°F)
Drift +2.6 µm +1.3 µm 0 -1.4 µm -3.2 µm
LS-3036
Temperature 0°C (32°F) 10°C (50°F) 20°C (68°F) 30°C (86°F) 40°C (104°F)
Drift +3.7 µm +1.7 µm 0 -1.7 µm -3.5 µm
When a rod 20 mm in diameter is measured at the center of the measuring
area [reference temperature: 20°C (68°F)].
LS-3060
Temperature 0°C (32°F) 10°C (50°F) 20°C (68°F) 30°C (86°F) 40°C (104°F)
Drift +8.6 µm +4.3 µm 0 -4.2 µm -8.4 µm
* Contact us for the data of LS-3033SO (8073)
APPENDIX B Characteristics
