46
CHAPTER 4 Functions and Controls
Retrieving (LOAD) Settings 1. Press PROG to display "PROG".
2. Enter the desired program No.
3. Press ENT to accept. At this moment, only the program No. has been
selected.
4. Use ON/OFF to move the cursor up to "LOAD".
5. Press SET to display "LO OK?". Press ENT to accept or CLR to cancel.
6. When you press ENT, the settings stored under the specified program No.
will be retrieved.
7. When you press CLR, you can resume from step 3.
R O G P 1
S A
L O A D
V E
Example of Operation Retrieving program No.3
Step Key operation Display
1 Press PROG.
2 Enter "3".
3 Press ENT.
4 Use UP/DOWN to move
cursor up to "LOAD".
5 Press SET.
6 Press ENT to retrieve.
• Program can be retrieved by using the program selector input terminals or
control I/O connector port. ➪ See P.62.
• See P.49 for storing and retrieving programs through the RS-232C inter-
face.
R O G P 3
S A
L O A D
V E
R O G P 1
S A
L O A D
V E
R O G P 3
S A
L O A D
V E
[ ]
R O G P 3
S A
L O O K
V E
?
R O G P 3
S A
L O A D
V E
R O G P 3
S A
L O A D
V E
R O G P 2
S A
L O O K
V E
?
