Specifies and outputs the setting status of the desired program.
The format differs with the setting information to be output, as described
below.
Format:
( [P$] [Ø$] ) [COMMAND] CR
Note that one or both of the commands in ( ) can be omitted.
When [P$] is omitted, the current program No. will be valid.
When [Ø$] is omitted, CH1 will be specified.
Output of Setting Status
Output Channel
Program No.
[P$] [Ø$] List
Function
Command
Description
Specifying and
X?
Outputs setting information of
outputting
segment selector X
setting information
Y?
Outputs setting information of
segment selector Y
XS?
Outputs whether segment check
for segment selector X is set to
ON or OFF
YS?
Outputs whether segment check
for segment selector Y is set to
ON or OFF
XN?
Outputs preset value of segment
check for segment selector X
YN?
Outputs preset value of segment
check for segment selector Y
TA?
Outputs preset value of HIGH3 for
7-level differentiation
TB?
Outputs preset value of HIGH2 for
7-level differentiation
TC?
Outputs preset value of HIGH1 for
7-level differentiation
TD?
Outputs preset value of LOW3 for
7-level differentiation
TE?
Outputs preset value of LOW2 for
7-level differentiation
[COMMAND] List
(To be continued)
Function
Command
Description
Specifying
P1
Specifies program No. 1
program No.
P2
Specifies program No. 2
P3
Specifies program No. 3
P4
Specifies program No. 4
P5
Specifies program No. 5
P6
Specifies program No. 6
P7
Specifies program No. 7
P8
Specifies program No. 8
P9
Specifies program No. 9
PA
Specifies program No. 10
Specifying output
V
Specifies CH1
channel
W
Specifies CH2
