60
CHAPTER 4 Functions and Controls
● Display digit suppress function
When the number of suppressed display digits is 0:
When the number of suppressed display digits is 3:
1st data 2nd data
0 C R
1st data 2nd data
3 C R
Program Example in BASIC Program 1
Pressing the space key of the computer allows the measured values to
appear on the computer display.
100 OPEN "COM1:4800,N,8,1,RS,CS,DS,CD" FOR RANDOM AS #1
110 A$=INKEY$
120 IF A$<>" " THEN 110
130 PRINT #1, "X0"
140 INPUT #1, B$
150 PRINT B$
160 GOTO 110
Program 2
The following settings are specified through the computer: SEG (2, 3), NOR-
MAL mode, upper and lower tolerance limits (20.0000 mm and 10.0000 mm),
number of measurements for averaging (512), and simple averaging mode.
After these settings are stored under program No. 3, the measured values are
displayed.
100 OPEN "COM1:4800,N,8,1,RS,CS,DS,CD" FOR RANDOM AS #1
110 PRINT #1, "S2, 3" Sets SEG (2, 3)
120 PRINT #1, "MN" Sets NORMAL mode
130 PRINT #1, "H20" Sets upper limit to 20.0000 mm
140 PRINT #1, "L20" Sets lower limit to 10.0000 mm
150 PRINT #1, "A9" Sets the number of measurements
for averaging to 512
160 PRINT #1, "BS" Sets simple averaging method
170 PRINT #1, "SV3" Saves settings into program
No.3
180 For I=1 TO 2000: NEXT I
190 PRINT #1, "X0"
200 PRINT #1, A$
210 PRINT A$ Display measured values
220 GOTO 190
