3-4 Message Communication
3-73
3
Communi
cat
in
g wit
h the
L
J
-V700
0 Ser
ies
- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
Profile data format
The following table shows the data format for profile data retrieved only when the
instance ID is 1. The data arranged in this format is split every 496 bytes.
* When N =800:
DINT Oct 31 30 29 28 27 26 - - - - 5 4 3 2 1 0 Remark
OUT1
measure-
ment value
information
0 0 Minimum display unit Refer to 3-18.
Note: All become
alarm status in
high-speed
mode.
* outputs the
confirmed data
status when the
profile confirma-
tion service is
executed.
1 4 OUT internal measurement value
Same as confirmed value
when Normal mode
2 8 OUT measurement value* Confirmed value
3 12 Judgment result*
For each of bit 0: HI, bit 1: GO,
and bit 2: LO,
0: OFF and 1: ON.
4 16 Measurement result information*
0:valid status/1: alarm
status/2: Judgment standby
5 20 Timing/auto-zero status
For each of bit 0: timing status
and bit 1: auto-zero status,
0: OFF and 1: ON.
-
OUT16
measure-
ment value
information
90 360 Minimum display unit
91 364 OUT internal measurement value
92 368 OUT measurement value*
93 372 Judgment result*
94 376 Measurement result information*
95 380 Timing/auto-zero status
Profile
information
96 384 Trigger count
97 388 Profile type
Bit 0: type. 1: 2 heads and Wide OFF, 0: Other
Bit 1: Compression (time axis). 1: ON, 0: OFF
98 392 Reserved
99 396 N data points of 1 profile Initial setting for N = 800
100 400 1st x-direction coordinate Integer of 0.01 m unit
101 404 X-direction pitch Integer of 0.01 m unit
Profile (1)
Head A
MAX
102 408 1st profile data Integer of 0.01 m unit
-
901 3604 Nth profile data Integer of 0.01 m unit
Profile (2)
Head A
MIX
902 3608 1st profile data
When compression (time axis) is OFF, profile data
is not stored in the Head A MIN or Head B MIN
area. (The profile data of Head B is stored as near
to the beginning of the area as possible.) The
Head B profile is stored only when 2 heads are
connected and Wide OFF is set.
-
1701 6804 Nth profile data
Profile (3)
Head B
MAX
1702 6808 1st profile data
-
2501 10004 Nth profile data
Profile (4)
Head B
MIX
2502 10008 1st profile data
-
3301 13204 Nth profile data
