- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
3-4 Message Communication
3-82
3
Communi
cat
in
g wit
h the
L
J
-V700
0 Ser
ies
(8) Initializing settings
Message communication initializes the settings for the specified program number of
a measuring instrument connected to the CB-EP100.
Service code 50H is used.
The following settings are required to use this object.
• Service code
• Class ID
• Instance ID
• Service Data
• Commands
• Response (when successful)
• Response (when failed)
Item Description Data Example
Service code Specify "initialize settings (50H)" (fixed value). 50H
Class ID CB Object (6BH) is specified (fixed value). 6BH
Instance ID 01H becomes a fixed value. 01H
Attribute ID There is no data. -
Service data
Specify the number of the program to initialize (00H to
0FH).
00000000H or
00000001H
Item Description Data Example
General status
Message communication returns status (00H) to notify
normal termination.
00H
Service response data There is no service response data. -
Item Description Data Example
General status Message communication returns a general status. 05H
Additional status Returns the additional status. -
Service response data There is no service response data. -
