- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
4-1
Specifications
The specifications of the CB-EP100 are as follows:
*1 When used with a switching hub there is no limit to the number of devices that
can be connected.
*2 The controller software must be in version 3 or later version.
Product name EtherNet/IP Network Unit
Model CB-EP100
Applicable network
EtherNet/IP and displacement meter proprietary protocol (socket
communication)
Ethernet
Compliant standards
IEEE802.3(10BASE-T)
IEEE802.3u(100BASE-TX)
Transmission rate
10Mbps (10BASE-T)
100Mbps (100BASE-TX)
Transmission medium
STP cable or Category 3 or higher UTP cable (10BASE-T)
STP cable or Category 5e or higher UTP cable (100BASE-TX)
Maximum cable length 100 m (distance between the CB-EP100 and Ethernet switch)
Maximum number of
connectable hubs *1
4 (10BASE-T)
2 (100BASE-TX)
EtherNet/IP
Compatible functions
Cyclic communication (Implicit message)
Message communication (explicit message)
Compatible with UCMM and Class 3
Number of connections 64
RPI 0.5 ms - 10000 ms (0.5 ms units)
Tolerable communication
bandwidth for cyclic
communication
6000pps
Message communication UCMM, Class 3
Conformance test Compatible with Version A9
Measuring
instrument
connection
Connectable devices *2
LJ-V7000 Series controller
LS-9000 Series controller
Number of connectable
devices
1 device
Indicators
Link/activity indicator (LINK/ACT): Green LED
Module status indicator (MS): Green and red 2-color LED
Network status indicator (NS): Green and red 2-color LED
Power voltage
Including 24 V DC +-10% ripple (P-P) (supplied by measuring
instrument controller unit)
Maximum current consumption 0.12A or less
Mass Approx. 470 g
