5-5 Objects for use with the CB-EP100
5-12
Identity Object
5
Ap
pe
ndi
x
- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
Reset service
The Reset service is a CIP standard function used to emulate the operation of turning
power on as closely as possible. When it accepts this service, the CB-EP100 stops
each function, interrupts communication, and reads the settings again. The Reset
service is used as a restart request for reflecting changed parameters (e.g., IP
address, etc.).
Execute this service by designating 01H as the Instance ID of the Identity object.
• The commands received during Reset processing may be discarded.
• The response for the Reset service is returned before the CB-EP100
starts reset processing.
List of general and additional statuses returned to each service
Service Code
Service Name
Service Data (1 Byte)
05H
Reset
00H: Emulates power reset. (Initial value)
01H: Restores the default settings and emulates power reset.
For details on the default settings, refer to
Settings" (Page 5-5).
• If the CB-EP100 receives the Reset service when 02H or higher is
set, 03H (Invalid parameter value) will be returned as the CIP
error code.
Point
Service
General
Status
Additional
(Extended)
Status
Description
Get_Attributes_
All
00H
-
The service has ended normally.
05H
-
The designated instance ID does not exist.
Reset
00H
-
The service has ended normally.
03H
-
The designated reset method is incorrect.
05H
-
The designated instance ID does not exist.
Get_Attribute_
Single
00H
-
The service has ended normally.
05H
-
The designated instance ID does not exist.
14H
-
The designated attribute ID does not exist.
Others
08H
-
The designated service is not supported.
