3-4 Message Communication
3-46
3
Communi
cat
in
g wit
h the
L
J
-V700
0 Ser
ies
0EH
308H
Judgment output
(HI)
For information on detailed formats,
refer to "Monitor Data (156 Words
(312 Bytes)) Assembly Instance
(Instance ID): 64H" (Page 3-9)
R WORD 309H
Judgment output
(LO)
30AH
Judgment output
(GO)
30BH
-
310H
Reserved
0EH
311H Timing status For information on detailed formats,
refer to "Monitor Data (156 Words
(312 Bytes)) Assembly Instance
(Instance ID): 64H" (Page 3-9)
R WORD
312H Auto-zero status
313H
-
316H
Reserved
0EH
317H Timing completion
For information on detailed formats,
refer to "Monitor Data (156 Words
(312 Bytes)) Assembly Instance
(Instance ID): 64H" (Page 3-9)
R WORD
318H
Auto-zero
completion
319H Reset completion
31AH
External input
completion
31BH
-
31EH
Reserved
0EH
31FH Timing failed
For information on detailed formats,
refer to "Monitor Data (156 Words
(312 Bytes)) Assembly Instance
(Instance ID): 64H" (Page 3-9)
R WORD
320H Auto-zero failed
321H Reset failed
322H
External input
failed
323H
-
325H
Reserved
0EH 326H
Change
programs
For information on detailed formats,
refer to "Monitor Data (156 Words
(312 Bytes)) Assembly Instance
(Instance ID): 64H" (Page 3-9)
R WORD
327H
-
32AH
Reserved
0EH 32BH
Current program
number
For information on detailed formats,
refer to "Monitor Data (156 Words
(312 Bytes)) Assembly Instance
(Instance ID): 64H" (Page 3-9)
R UDINT
32CH Reserved
Service
code
(hexadecimal)
Attribute
ID
(hexadecimal)
Name Description and service data Attribute Data type
