- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
3-3 Cyclic communication
3-18
3
Communi
cat
in
g wit
h the
L
J
-V700
0 Ser
ies
OUT measurement
value
OUTn (n: 1 - 16)
Stores all OUT measurement values (32-bit DINT type
Measurement values are output in the following units depending on
measurement mode.
Length (height, width, etc.): 0.01 m units
Example: 1234560
⇒12345.60
m
Cross-sectional area: 0.00001mm
2
units
Example: 123456
⇒ 1.23456mm
2
Angle: 0.001 units
Example: 12340
⇒ 12.340
* The OUT measurement value results in an alarm in the following cases.
• When measurement mode is "No measurement"
• When operation mode is "High-speed mode"
* When the OUT measurement value status is judgment standby, 80000001H
is returned.
* When the OUT measurement value status is alarm, 80000000H is returned.
* For details on how to obtain the current value, refer to page 3-24.
OUT measurement
value update count
OUTn (n: 1 - 16)
Each time measurement values are output and updated, the count is
incremented by 1.
The count range is 0 to 65535 and 65535 is incremented to 0.
OUT measurement
value display unit
OUTn (n: 1 - 16)
Stores all OUT measurement value display units.
In the following cases, the display unit for OUT measurement values becomes 0
(initial value).
• When measurement mode is "No measurement"
• When operation mode is "high-speed mode"
Number of storage
data points
Stores the current number of storage data points (32-bit DINT type).
Item
Description
Display unit code
Minimum display unit setting
0
1mm
1
0.1mm
2
0.01mm
3
0.001mm
4
1μm
5
0.1μm
100
1mm
2
101
0.1mm
2
102
0.01mm
2
103
0.001mm
2
104
0.0001mm
2
105
0.00001mm
2
200
1deg
201
0.1deg
202
0.01deg
