Message Router Object
5
Ap
pe
ndi
x
- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
„ List of general and additional statuses returned to each service
This object directly accesses and controls the data, which is exchanged via cyclic
communication, via message communication. It can be used to send data to a
scanner that does not support cyclic communication.
„ Class
z Class service
Get_Attribute_Single (0EH) is supported.
z Class attribute (instance ID: 00H)
„ Instance
z Instance service
Get_Attribute_Single (0EH) and Set_Attribute_Single (10H) are supported.
z Instance attribute (instance ID: 64H to 65H)
The interface ID is assigned when using instances to set tags.
Instance ID: 64H to 65H
*1 When the instance ID of the target ID is 64H, the attribute is R.
*2 Reading with Get_Attribute_Single ensures synchronism in instance IDs.
*3 For details on the data assigned to each instance ID, refer to "Monitor data"
(instance ID: 64H) and "Control data" (instance ID: 65H) of each measuring
instrument. Page 3-20
Name
General
Status
Additional
(Extended)
Status
Description
Get_Attribute_Single
00H - The service has ended normally.
05H - The designated instance ID does not exist.
14H - The designated attribute ID does not exist.
Others 08H - The designated service is not supported.
Assembly Object (Class ID: 04H)
Attribute ID Name Description Attribute
Data
Type
Parameter
Range
01H Revision Object revision R UINT 0002H
Attribute ID Name Description Attribute
Data
Type
Parameter
Range
03H Data
Data assigned to Instance
ID
R/W
*1
Array of
BYTEs
Number of bytes
assigned to instance
ID
*2*3
04H Size
Number of bytes
assigned to Instance ID
R UINT
Set size assigned to
instance ID (byte
unit)
