- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
3-4 Message Communication
3-80
3
Communi
cat
in
g wit
h the
L
J
-V700
0 Ser
ies
• Responses (when failed)
For details on the attribute ID, settings, general status, and additional status of each
parameter, refer to
"CB Object (Class ID:6BH)" (Page 3-40) and
(6) Requesting to reflect setting write area
Message communication reflects the contents of the setting write area of the
measuring instrument connected to the CB-EP100 up to the specified hierarchy level.
Service code 4EH is used.
The following settings are required to use this object.
• Service code
• Class ID
• Instance ID
• Service Data
• Commands
• Response (when successful)
• Response (when failed)
Item
Description
Data Example
General status
A general status for the service is returned
08H
Additional status
An additional status is returned.
-
Service response data
There is no service response data.
-
Item
Description
Data Example
Service code
Specify "request to reflect setting write area (4EH)"
(fixed value).
4EH
Class ID
CB Object (6BH) is specified (fixed value).
6BH
Instance ID
01H becomes a fixed value.
01H
Attribute ID
There is no attribute ID.
-
Service data
Specify the reflection destination area (0 = setting area
currently in operation, 1 = save area)
00000000H or
00000001H
Item
Description
Data Example
General status
Message communication returns status (00H) to notify
normal termination.
00H
Service response data
There is no service response data.
-
Item
Description
Data Example
General status
Message communication returns a general status.
05H
Additional status
Returns the additional status.
-
Service response data
There is no service response data.
-
