3-4 Message Communication
3-55
3
Communi
cat
in
g wit
h the
L
J
-V700
0 Ser
ies
- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
0EH
9F0H
[OUT4 setting]
measurement
value hold count
Specifies a measurement value hold
count (0 - 999).
R DINT
9F1H
[OUT4 setting]
measurement
value filter
0: OFF
1: Moving average
2: Low-pass filter
3: High-pass filter
9F2H
[OUT4 setting]
measurement
value filter details
Moving average mode
⇒ 0: 4 times,
1: 16 times, 2: 64 times, 3: 256 times,
4: 1024 times, 5: 4096 times
High-pass, low-pass
⇒ 0: 0.1 Hz,
1: 0.3 Hz, 2: 1 Hz, 3: 3 Hz, 4: 10 Hz,
5: 30 Hz, 6: 100 Hz, 7: 300 Hz,
8: 1000 Hz
9F3H
[OUT4 setting]
hold modes
0: Normal, 1: Peak hold, 2: Bottom
hold, 3: Peak-to-peak hold, 4: Aver-
age hold, 5: Sample hold, 6: Peak, 7:
Bottom, 8: Peak-to-peak, 9: Average
(0 to 5 can be set when batch mea-
surement is OFF, and 6 to 9 can be
set when batch measurement is ON.)
9F4H
[OUT4 setting]
scaling measure-
ment value 1
Set each measurement value with the
following units depending on the mea-
surement mode.
„ Length (height, width, etc.):
0.01 m units
Example:
1234560
⇒ 12345.60m
„ Cross-sectional area:
0.00001mm
2
units
Example:
123456
⇒ 1.23456mm 2
„ Angle: 0.001 units
Example: 12340
⇒ 12.340
9F5H
[OUT4 setting]
scaling display
value 1
9F6H
[OUT4 setting]
scaling measure-
ment value 2
9F7H
[OUT4 setting]
scaling display
value 2
9F8H
[OUT4 setting]
offset
9F9H
[OUT4 setting]
Upper tolerance limit
9FAH
[OUT4 setting]
Lower tolerance limit
9FBH
[OUT4 setting]
Tolerance hysteresis
9FCH
[OUT4 setting]
zero reference value
9FDH
[OUT4 setting]
Zero terminal
0 None, 1: ZERO1, 2: ZERO2
9FEH
[OUT4 setting]
TIMING/RESET
terminal
0: None, 1: TIMNG1/RESET1,
2: TIMING2/RESET2
9FFH
-
A0FH
Reserved
Service
code
(hexadecimal)
Attribute
ID
(hexadecimal)
Name Description and service data Attribute Data type
