- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -

3-3 Cyclic communication

3-16

Communi

cat

g wit

h the

-V700

0 Ser

ies

Judgment output
(HI) OUTn
(n:1 - 16)

Indicates judgment output status of each OUT measurement value.
1 is stored in this bit when judgment output status is HI.
ON: Judgment output is HI.
OFF: Judgment output is not HI.

Judgment output
(LO) OUTn
(n:1 - 16)

Indicates judgment output status of each OUT measurement value.
1 is stored in this bit when judgment output status is LO.
ON: Judgment output is LO.
OFF: Judgment output is not LO.

Judgment output
(GO) OUTn
(n:1 - 16)

Indicates judgment output status of each OUT measurement value.
1 is stored in this bit when judgment output status is GO.
ON: Judgment output is GO.
OFF: Judgment output is not GO.

Timing status
OUTn
(n: 1 - 16)

Outputs the timing status for each OUT measurement value.
ON: Timing is ON
OFF: Timing is OFF

Auto-zero status
OUTn
(n: 1 - 16)

Outputs the auto-zero status for each OUT measurement value.
ON: Auto-zero is ON
OFF: Auto-zero is OFF

Timing completion
OUTn (n: 1 - 16)

Indicates whether the timing input request for measurement values has been
completed (when successful).
ON: Timing input request has been completed (when successful)
OFF: Timing input request has not been completed (when not successful)

Auto-zero
completion
OUTn (n: 1 - 16)

Indicates whether the auto-zero input request for OUT measurement values has
been completed (when successful).
ON: Auto-zero input request has been completed (when successful)
OFF: Auto-zero input request has not been completed (when not successful)

Reset completion
OUTn (n: 1 - 16)

Indicates whether the reset input request for OUT measurement values has
been completed (when successful).
ON: Reset input request has been completed (when successful)
OFF: Reset input request has not been completed (when not successful)

Trigger completion

Indicates whether the external trigger request has been completed (when
successful).
ON: External trigger request has been completed (when successful)
OFF: External trigger request has not been completed (when not successful)

Batch start
completion

Indicates whether the batch start request has been completed (when
successful).
ON: Batch start request has been completed (when successful)
OFF: Batch start request has not been completed (when successful)

Batch end
completion

Indicates whether the batch end request has been completed (when
successful).
ON: Batch end request has been completed (when successful)
OFF: Batch end request has not been completed (when not successful)

Storage start
completion

Indicates whether the storage start request has been completed (when
successful).
ON: Storage start request has been completed (when successful)
OFF: Storage start request has not been completed (when not successful)

Storage stop
completion

Indicates whether the storage end request has been completed (when
successful).
ON: Storage end request has been completed (when successful)
OFF: Storage end request has not been completed (when not successful)

Error clear
completion

Indicates whether the error clear request has been completed (when
successful).
ON: Error clear request has been completed (when successful)
OFF: Error clear request has not been completed (when not successful)
