- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
3-4 Message Communication
3-40
3
Communi
cat
in
g wit
h the
L
J
-V700
0 Ser
ies
The CB Object provides the CB-EP100 connection status and device write/read. This
object is unique to the CB-EP100.
Overview of CB object
The following table shows a simplification of what data is included at positions
indicated by attribute IDs and instance IDs. (A gray area is reserved.) For actual
use, a service code and service data are also required. (In some cases, service
data may not be required.)
R = read-only, RW = Read and write Also, with instance IDs of 100 to 115 and
200 to 215, the last two digits are the program number.
With instance ID = 1, the settings for the program number at that time can be
referred to.
* The same data as the measurement values/judgment values of instance ID = 1
can be acquired.
CB Object (Class ID:6BH)
Attribute ID range Instance ID
Start ID End ID
Quantity
0 1 100 115 200 215
DEC HEX DEC HEX
R/W: Cyclic
data
R: Measuring
instrument
status
R: Active
measurement
area
R/W: Setting
write area
100 64 109 6D 10
Monitor data*
Error code/
device status
110 6E 118 76 9
For unique service
(control input)
119 77 159 9F 41
160 A0 198 C6 39
199 C7 767 2FF 569
768 300 847 34F 80
Monitor data 848 350 848 350 1 Port No.
849 351 861 35D 13
862 35E 879 36F 18
880 370 927 39F 48 Profile data
928 3A0 2447 98F 1520
2448 990 2942 B7E 495
Current
program
setting values
Program setting
values of No**
Program setting
values of No**
2943 B7F 3263 CBF 321
3264 CC0 3327 CFF 64
Device name/
revision
(**: Last two digits of the instance ID)
