- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
3-4 Message Communication
3-86
3
Communi
cat
in
g wit
h the
L
J
-V700
0 Ser
ies
(12)Initializing all setting values of a measuring instrument
Message communication returns all settings in measuring instrument connected to
the CB-EP100 to their default values.
Service code 5FH is used.
The following settings are required to use this object.
• Service code
• Class ID
• Instance ID
• Commands
• Response (when successful)
• Response (when failed)
Item Description Data Example
Service code Specify "Initializes all settings (5FH)" (fixed value). 5FH
Class ID CB Object (6BH) is specified (fixed value). 6BH
Instance ID 01H becomes a fixed value. 01H
Attribute ID There is no attribute ID. -
Service data There is no data -
Item Description Data Example
General status
Message communication returns status (00H) to notify
normal termination.
00H
Service response data There is no service response data. -
Item Description Data Example
General status Message communication returns a general status. 05H
Additional status Returns the additional status. -
Service response data There is no service response data. -
