3-4 Message Communication
3-77
3
Communi
cat
in
g wit
h the
L
J
-V700
0 Ser
ies
- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
(4) Clearing errors
Message communication clears the error status of the CB-EP100 and a measuring
instrument connected to the CB-EP100.
Service code 4CH is used.
The following settings are required to use this object.
• Service Code
• Class ID
• Instance ID
• Commands
• Responses (when successful)
• Responses (when failed)
Item Description Data Example
Service Code Specify "clear errors (4C)" (fixed value). 4CH
Class ID Designates CB Object (6BH)(fixed value). 6BH
Instance ID
There is no change in the operation with the ID number
but 00H or 01H needs to be specified.
00H/01H
Attribute ID There is no data. -
Service Data There is no service data -
Item Description Data Example
General status Message communication has ended normally. 00H
Service response data There is no service response data. -
Item Description Data Example
General status A general status for the service is returned 08H
Additional status An additional status is returned. -
Service response data There is no service response data. -
