- EtherNet/IP Network Unit CB-EP100 User’s Manual (LJ-V7000 Edition) -
3-4 Message Communication
3-42
3
Communi
cat
in
g wit
h the
L
J
-V700
0 Ser
ies
Responses
The responses made when each service is used are as follows:
(1) Read setting values
Service code 0EH
(2) Write setting values Service code 10H
(3) Switching the programs Service code 4BH
(4) Clear errors Service code 4CH
(5) Input control data Service code 4DH
(6) Request to reflect setting write area Service code 4EH
(7) Update setting write area Service code 4FH
(8) Initialize program settings Service code 50H
(9) Confirm profile data Service code 57H
(10) Set date and time Service code 58H
(11) Acquire date and time Service code 59H
(12) Initializes all settings Service code 5FH
* An additional status is a 4-digit hexadecimal value of ( H).
: Target setting One of 0 = no error and 7 = OUT setting
: Program number 0 to F
: OUT number 0 to F
: Error code Depends on the cause of the error. Refer to "Error code list."
General
status
Service code (hexadecimal)
Description
5 E 10 4B 4C 4D 4E 4F 50 57 58 59 5F
00H The service has ended normally.
05H The instance ID is out of the range.
08H
This service cannot be executed with the
specified instance ID.
09H The written data is out of the range.
0CH
Execution of control input failed.
A failure occurred during the execution of the
requested operation.
0EH
Writing was attempted to unwriteable attribute
ID.
13H The service data size is smaller than specified.
14H The attribute ID is out of the range.
1FH
This service is supported with the specified
instance ID, but it cannot be used with the
specified attribute ID. (Additional status
C350H)
20H
The parameters associated with the request
are invalid. Returns the detailed code for
inconsistent settings that the measuring
instrument stores as additional status.*
FEH
A system error in the CB-EP100 or in a meas-
uring instrument connected to the CB-
EP100.
