Right side view
Right side view, closed
The following picture shows the right side of the analyzer with the side door closed, as seen from the
front:
Legend:
1 Right side door
2 Main switch
Right side view, open
The following picture shows the right side of the analyzer with the side door open, as seen from the
front:
Legend:
1 Mainboard
2 Furnace
3 Main switch
