Operation Manual D-480 ©BÜCH Labortechnik AG
3 - Product description 36
Top view furnace
The following picture shows a top view of the furnace pulled out:
Legend:
1 Post combustion tube plug
2 Post combustion tube
3 Combustion tube connection
4 Combustion tube
5 Reduction tube plug
6 Reduction tube
Rear view
Rear view
The following picture shows the rear view of the analyzer:
Legend:
1 Rear wall
2 Air baffle
3 "PC" PC connector (USB)
4 "Reserve" reserve
5 "~" mains connector
6 "CO
2
IN" CO
2
gas inlet
7 "O
2
IN" O
2
gas inlet
8 "REF" reference gas outlet
9 "WASTE" measuring gas outlet
