Operation Manual D-480 ©BÜCH Labortechnik AG
10 - Menu and dialog descriptions 267
Printer setup (Dialog)
Function
In this dialog you can specify the printer and its connection. The appearance of this dialog depends
on the type of printer installed / activated.
Open
Open the dialog by selecting File > Printer Setup.
Elements
The following describes the elements of the dialog.
In section "Printer":
Label Element type Meaning
Name Dropdown listbox Field displaying a list of printers connected to the
computer.
Properties Button Opens a dialog in which you can define the properties of
the printer selected on the left in the "Name" field.
Status Label Displays the status of the selected printer.
Type Label Displays the type of the selected printer.
Location Label Displays the location of the selected printer.
Comment Label Displays a comment on the printer.
Note: Use the Windows control panel to install printers and configure printer connections.
In section "Paper":
Label Element type Meaning
Size Dropdown listbox Field in which you can select the size of the paper to print
on.
Source Dropdown listbox Field to select the paper tray.
In section "Alignment":
Label Element type Meaning
Portrait Radiobutton The page is in portrait format.
Landscape format Radiobutton The page is in landscape format.
Remaining elements:
Label Element type Meaning
Network Button Connects to a shared network.
OK Button Saves new settings
Cancel Button Discards settings not yet saved.
Further information
Further information includes instructions in which the dialog is used and knowledge articles
concerning the dialog:
 Printer setup (on page 103).
