Operation Manual D-480 ©BÜCH Labortechnik AG
10 - Menu and dialog descriptions 314
Valid for all tabs:
Remaining elements:
Label Element type Meaning
OK Button Saves new settings
Cancel Button Discards settings not yet saved.
Further information
Further information includes instructions in which the dialog is used and knowledge articles
concerning the dialog:
 Exporting LIMS data (on page 160)
 Defining the LIMS / PC interface (on page 86).
 Laboratory information and management system (LIMS) (on page 72).
 LIMS export settings (on page 81).
Device parameters (Dialog)
Function
This dialog serves to display and edit instrument parameters. The dialog has several options, that are
accessible on the left via the navigation panel.
Open
Open the dialog via Options > Settings > Parameters.
Elements
The following describes the elements of the dialog.
In section "Temperatures":
Label Element type Meaning
Comb. tube Textbox Field to input the setpoint temperature of the combustion
tube (middle furnace).
Post comb. tube Textbox Field to input the setpoint temperature of the post
combustion tube (left furnace).
Reduction tube Textbox Field to input the temperature of the reduction tube
(furnace right).
In section "O2 dosing":
Label Element type Meaning
O2 delay Textbox Field to input a time. Defines the time to wait after
loading before beginning O
2
dosing.
Maximum O2 dosing time Textbox Field to input a time. Defines the maximum duration of
the oxygen dosing.
In section "Integration time values":
Label Element type Meaning
Autozero delay Textbox Field to input a time. Defines the time to wait after
introduction until the system performs autozero
alignment.
