BUCHI DuMaster D-480 - Manual (Page 329)

Operation Manual D-480 ©BÜCH Labortechnik AG
10 - Menu and dialog descriptions 329
Elements
The following describes the elements of the dialog.
Label Element type Meaning
Total Radiobutton Defines that the total area shall be used for the
assignment.
"Superimposed" peak Radiobutton Defines that the area of the superimposed peak (ligh red
color) shall be used for the assignment. (Not available for
single peak integration)
Socket Radiobutton Defines that the area of the socket (light blue color) shall
be used for the assignment. The area value of the socket is
the difference between the total area and the area of the
superimposed peak. (Not available for single peak
integration)
{Element name} Option fields Define the element to which the selected peak area shall
be assigned. The number of option fields and their labeling
depend on the set analysis mode.
OK Button Executes the assignment and closes the dialog. After the
assignment the assigned area and the resulting new
element content are displayed in the sample view.
Cancel Button Closes the dialog without assignment.
Further information
Further information includes instructions in which the dialog is used and knowledge articles
concerning the dialog:
 Manual peak integration (on page 152).
Standard samples display (Dialog)
Function
In this dialog, you select how the standard samples are displayed in the sample field.
Open
Open the dialog via Math > Standard samples.
Elements
The following describes the elements of the dialog.
Label Element type Meaning
Show as standard sample
(theoretical concentration) Radiobutton The sample filed displays the theoretical element
concentrations of the standard samples in the
corresponding columns.
Show as factor/monitor
sample (measured
concentration) Radiobutton The sample filed displays the measured (calculated)
element concentrations of the standard samples in
the corresponding columns.
OK Button Saves new settings
Cancel Button Discards settings not yet saved.
