BUCHI DuMaster D-480 - Manual (Page 130)

Operation Manual D-480 ©BÜCH Labortechnik AG
7 - Using the instrument 130
Software usage rules
Software usage rules
Observe th following rules in order to avoid disruptions during analysis:
 The control PC must not be used simultaneously as an office workstation as this may lead to
software instability.
 Observe the following if using the operating software and other software at the same time:
 Programs that require a lot of computer processing capacity or access disk drives for long
periods (e.g. disk formatting) may cause disruptions.
 Programs that access the same serial interface as the analyzer operating software cause
the analyzer to crash totally! Therefore, avoid running multiple programs simultaneously if
you are not sure about how they work.
 Only standard Windows screensavers may be used.
Starting the operating software
Starting the operating software
Proceed as follows:
 Launch the operating software:
 by double-clicking the appropriate icon on your screen or
 by launching the program via Start > Programs or
 by executing the program via the appropriate path.
 Enter the following in the "Log in as" dialog:
In the field...
 ... "User" enter your user name.
 ... "Password" enter your password.
 ... "Domain" enter the name of your domain if the PC is connected to a network and the
user management is defined on that network. If the PC is operated without a network or the
user management is defined on the local PC this field has to be kept empty.
 Click OK in the "Log in as" dialog. The user interface is displayed.
Showing or hiding the toolbar
Showing or hiding the toolbar
Select Windows > Toolbar to show or hide the toolbar:
 If the menu command is checked, the toolbar is displayed.
 If the menu command is not checked, the toolbar is hidden.
Waking up the instrument
Waking up the instrument
Proceed as follows:
 Wake up the analyzer by selecting System > Wake Up.
