Operation Manual D-480 ©BÜCH Labortechnik AG
10 - Menu and dialog descriptions 263
Label Element type Meaning
Cancel Button Aborts the process and discards settings not yet saved.
Further information
Further information includes instructions in which the dialog is used and knowledge articles
concerning the dialog:
 Exporting LIMS data (on page 160).
 Laboratory information and management system (LIMS) (on page 72).
 LIMS export settings (on page 81).
 Conditions for operating the LIMS.
 LIMS settings (on page 311).
Export peak graphics (Dialog)
Function
In this dialog you can define settings for exporting graphic data. For each sample for which a graphic
shall be exported a text file will be created. The names of these files have the following format:
easgraph.xxx,
where xxx represents the serial number of the corresponding sample (e.g. "easgraph.001" for sample
no. 1 etc.). If a file with the same name already exists, the content of this file will be overwritten with
the new graphic information.
Open
Open the dialog by selecting File > Export/Import > Export graphics.
Elements
The following describes the elements of the dialog.
Label Element type Meaning
export all samples Radiobutton The graphic data of all samples listed in the sample view
will be exported. For each sample a new file will be
generated.
export only
selected samples Radiobutton The graphic data of the samples marked in the sample
view will be exported. For each sample a new file will be
generated.
Directory Textbox Defines the name of the directory where the graphic files
shall be filed.
... Button Allows the selection of the directory via the dialog "Browse
for folder".
OK Button Starts the export according to the settings.
Cancel Button Aborts the process and discards settings not yet saved.
Configure report (Dialog)
Function
In this dialog you can define up to three headers to appear on every page of the log printout and the
type of printout.
