Operation Manual D-480
©BÜCH Labortechnik AG
10 - Menu and dialog descriptions
254
Dialog descriptions key
Element types
The following list provides pictures of element types that feature in the dialog descriptions:
Element type
Example picture
Label
Dropdown listbox
Checkbox
Listbox
Radiobutton
Button
Sliding controller
Listbox column
Textbox
Textbox/label
Textbox with checkbox
Textbox with buttons
