Operation Manual D-480 ©BÜCH Labortechnik AG
8 - Maintaining the instrument 212
Installing the O
2
lance
Proceed as follows:
 Pull on the lance connector (2) at the end of the O
2
lance (3). Insert the O
2
lance with the
connector into the 3 mm bore (1) located across from the flap with hinge up to the stop. Avoid
breakage of the lance by slight rotary motions while inserting.
 After insertion the sealing hose must be set in completely into the bore and must not stick out.
