Manageability Engine (ME) events System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
90 Intel order number G74211-001 Revision 1.0
15. Manageability Engine (ME) events
The Manageability Engine controls the PECI interface and also contains the Node Manager functionality.
15.1 Node Manager Exception Event
A Node Manager Exception Event will be sent each time when maintained policy power limit is exceeded over Correction Time Limit.
Table 85: Node Manager Exception Sensor Typical Characteristics
Byte Field Description
8
9
Generator ID 002Ch – ME Firmware
11 Sensor Type DCh = OEM
12 Sensor Number 18h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 72h (OEM)
14 Event Data 1
[7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3] – Node Manager Policy event
0 – Reserved
1 – Policy Correction Time Exceeded – policy did not meet the contract for the defined policy. The policy will continue to limit the
power or shutdown the platform based on the defined policy action.
[2] – Reserved
[1:0] – 00b
15 Event Data 2
[4:7] – Reserved
[0:3] – Domain Id (Currently, supports only one domain, Domain 0)
16 Event Data 3 Policy Id
