System Event Log Troubleshooting Guide for Intel ® S5500/S3420 series Server Boards Cooling subsystem
Revision 1.0 Intel order number G74211-001 33
Byte Field Description
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 08h ( Generic ‘digital’ Discrete)
14 Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset as described in Table 30
15 Event Data 2 Not used
16 Event Data 3 Not used
The following table describes the severity of each of the event triggers for both assertion and for deassertion.
Table 30: Fan Presence Sensors – Event Trigger Offset – Next Steps
Event Trigger Offset
Assertion
Severity
Deassert
Severity
Description Next Steps
Hex Description
01h
Device
Present
OK Degraded
Assertion –A fan was inserted. This
event may also get logged when the
BMC initializes when AC is applied. Informational only
Deassert – A fan was removed, or
was not present at the expected
location when the BMC initialized
These events only get generated in systems with hot-swappable fans, and normally
only when a fan is physically inserted or removed. If fans were not physically removed:
1. Use the Quick Start Guide to check if the right fan headers were used.
2. Swap the fans round to see if the problem stays with the location, or follows
the fan.
3. Replace fan or fan wiring/housing depending on the outcome of step 2.
4. Ensure the latest FRUSDR update has been run and the correct chassis was
detected or selected.
