Cooling subsystem System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
38 Intel order number G74211-001 Revision 1.0
Byte Field Description
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 01h (Threshold)
14 Event Data 1
[7:6] – 01b = Trigger reading in Event Data 2
[5:4] – 01b = Trigger threshold in Event Data 3
[3:0] – Event Triggers as described in Table 37
15 Event Data 2 Reading that triggered event.
16 Event Data 3 Threshold value that triggered event.
Table 37: Thermal Margin Sensors Event Triggers – Description
Event Trigger Assertion
Severity
Deassert
Severity
Description
Hex Description
07h
Upper non critical
going high
Degraded OK The thermal margin has gone over its upper non critical threshold.
09h
Upper critical
going high
non-fatal Degraded The thermal margin has gone over its upper critical threshold.
Table 38: Thermal Margin Sensors – Next Steps
Sensor
Number
Sensor Name
Next Steps
22h IOH Therm Margin 1. Check for clear and unobstructed airflow into and out of chassis.
2. Ensure SDR is programmed and correct chassis has been selected.
3. Ensure there are no fan failures.
4. Ensure the air used to cool the system is within the thermal specifications for the system (typically below 35°C).
23h Mem P1 Therm Margin
24h Mem P2 Therm Margin
62h P1 Therm Margin
Not a logged SEL event. Sensor is used for thermal management of the processor.
63h P2 Therm Margin
