System Event Log Troubleshooting Guide for Intel ® S5500/S3420 series Server Boards Memory subsystem
Revision 1.0 Intel order number G74211-001 55
Byte Field Description
16 Event Data 3 Not used.
Table 57: Sparing Configuration Status Sensor Event Trigger Offset – Next Steps
Event Trigger Offset
Description Next Steps
Hex Description
01h
The system has configured into
Spare Channel RAS mode. Sparing mode is enabled in
setup.
Informational event only.
00h
The system has configured out of
Spare Channel RAS mode
Sparing mode is disabled,
either from setup or due to
error in which case post error
8500 also occurs.
1. If this event is accompanied by a post error 8500, there was a problem applying
the sparing configuration to the memory. Check for other errors related to the
memory and troubleshoot accordingly.
2. If there is no post error then sparing mode was simply disabled in bios setup and
this should be considered informational only.
