System Event Log Troubleshooting Guide for Intel ® S5500/S3420 series Server Boards Hot Swap Controller events
Revision 1.0 Intel order number G74211-001 89
Byte Field Description
08h = Drive Slot 0 Presence
09h = Drive Slot 1 Presence
0Ah = Drive Slot 2 Presence
0Bh = Drive Slot 3 Presence
0Ch = Drive Slot 4 Presence
0Dh = Drive Slot 5 Presence
0Ah = Drive Slot 0 Presence
0Bh = Drive Slot 1 Presence
0Ch = Drive Slot 2 Presence
0Dh = Drive Slot 3 Presence
0Eh = Drive Slot 4 Presence
0Fh = Drive Slot 5 Presence
10h = Drive Slot 6 Presence
11h = Drive Slot 7 Presence
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 08h ( ‘digital’ Discrete)
14 Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset
0h = Device Removed/Device Absent.
1h= Device Inserted/Device Present
15 Event Data 2 Not used.
16 Event Data 3 Not used.
14.3.1 HSC Drive Presence Sensor – Next Steps
On AC power on the drive presence will be logged as an informational event.
If during normal operation a drive is removed or installed it will also log an event.
If you get a drive removed or installed without operator intervention then ensure that the drive was seated properly and the drive carrier was
properly latched.
