Miscellaneous events System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
82 Intel order number G74211-001 Revision 1.0
13. Miscellaneous events
The miscellaneous events section addresses sensors not easily grouped with other sensor types.
13.1 IPMI Watchdog
EPSD server systems support an IPMI watchdog timer, which can check to see if the OS is still responsive. The timer is disabled by default,
and would have to be enabled manually. It then requires an IPMI-aware utility in the operating system that will reset the timer before it expires.
If the timer does expire, the BMC can take action if it is configured to do so: (reset, power down, power cycle, or generate a critical interrupt)
Table 76: IPMI Watchdog Sensor Typical Characteristics
Byte Field Description
11 Sensor Type 23h = Watchdog 2
12 Sensor Number 03h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14 Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset as describe in Table 77
15 Event Data 2 Not used.
16 Event Data 3 Not used.
