Sensor Cross Reference List
System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
14
Intel order number G74211-001
Revision 1.0
3.4 Hot Swap Controller Firmware owned Sensors (GID = 00C0h/00C2h)
The following table can be used to find the details of sensors owned by the Hot Swap Controller (HSC) firmware. The HSC firmware resides on
a Hot Swap Back Planes (HSBP). There can be up to two HSBP in a system. Each HSBP will have its own GID.
00C0h = HSC Firmware
– HSBP A
00C2h = HSC Firmware
– HSBP B
Table 8: Hot Swap Controller Firmware owned Sensors
Sensor
Number
Sensor Name
Details Section
Next Steps
01h
Backplane Temperature
HSC Backplane Temperature Sensor
Table 82: HSC Backplane Temperature Sensor
– Event Trigger Offset – Next Steps
02h
Drive Slot 0 Status
03h
Drive Slot 1 Status
04h
Drive Slot 2 Status
05h
Drive Slot 3 Status
06h
Drive Slot 4 Status
07h
Drive Slot 5 Status
6 Slot HSBP
08h
Drive Slot 0 Presence
09h
Drive Slot 1 Presence
0Ah
Drive Slot 2 Presence
0Bh
Drive Slot 3 Presence
0Ch
Drive Slot 4 Presence
0Dh
Drive Slot 5 Presence
8 Slot HSBP
08h
Drive Slot 6 Status
