System Event Log Troubleshooting Guide for Intel ® S5500/S3420 series Server Boards
Basic decoding of a SEL Record
Revision 1.0 Intel order number G74211-001 7
Table 3: OEM SEL Record (Type C0h-DFh)
Byte Field Description
1
2
Record ID
(RID) ID used for SEL Record access.
3 Record Type
(RT) [7:0] - Record Type
C0h-DFh = OEM timestamped, bytes 8-16 OEM defined
4
5
6
7
Timestamp
(TS) Time when event was logged. LS byte first.
Example: TS:[29][76][68][4C] = 4C687629h = 1281914409 =Sun, 15 Aug 2010
23:20:09 UTC
Note: There are various websites that will convert the raw number to a date/time.
8
9
10
Manufacturer ID LS Byte first. The manufacturer ID is a 20-bit value that is derived from the IANA
‘Private Enterprise’ ID.
Most significant four bits = reserved (0000b).
000000h = unspecified. 0FFFFFh = reserved.
This value is binary encoded.
For example the ID for the IPMI forum is 7154 decimal, which is 1BF2h, which would
be stored in this record as F2h, 1Bh, 00h for bytes 8 through 10, respectively.
11
12
13
14
15
16
OEM Defined OEM Defined. This is defined according to the manufacturer identified by the
Manufacturer ID field.
Table 4: OEM SEL Record (Type E0h-FFh)
Byte Field Description
1
2
Record ID
(RID) ID used for SEL Record access.
3 Record Type
(RT) [7:0] - Record Type
E0h-FFh = OEM system event record
4
5
6
7
8
9
10
11
12
13
14
15
16
OEM OEM Defined. This is defined by the system integrator.
