Sensor Cross Reference List System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
12 Intel order number G74211-001 Revision 1.0
Sensor
Number
Sensor Name Details Section Next Steps
66h
Processor 1 VRD Temp
(P1 VRD Hot)
Discrete Thermal Sensors Table 43: Discrete Thermal Sensors
67h
Processor 2 VRD Temp
(P2 VRD Hot)
Discrete Thermal Sensors Table 43: Discrete Thermal Sensors
68h
Catastrophic Error
(CATERR)
Catastrophic Error Sensor Catastrophic Error Sensor – Next Steps
69h
CPU Missing
(CPU Missing)
CPU Missing Sensor CPU Missing Sensor – Next Steps
6Ah
IOH Thermal Trip
(IOH Thermal Trip)
Discrete Thermal Sensors Table 43: Discrete Thermal Sensors
3.2 BIOS POST owned Sensors (GID = 0001h)
The following table can be used to find the details of sensors owned by BIOS POST.
Table 6: BIOS POST owned Sensors
Sensor
Number
Sensor Name Details Section Next Steps
01h Mirroring Redundancy State Mirrored Redundancy State Sensor Table 55: Mirrored Redundancy State Sensor Event Trigger Offset – Next Steps
06h POST Error
System Firmware Progress (Formerly
Post Error)
System Firmware Progress (Formerly Post Error) – Next Steps
11h Sparing Redundancy State Sparing Redundancy State Sensor Table 59: Sparing Redundancy State Sensor Event Trigger Offset – Next Steps
12h Mirroring Configuration Status Mirroring Configuration Status Table 53: Mirroring Configuration Status Sensor Event Trigger Offset – Next Steps
13h Sparing Configuration Status Sparing Configuration Status Table 57: Sparing Configuration Status Sensor Event Trigger Offset – Next Steps
83h System Event System Events Not applicable
