System BIOS events
System Event Log Troubleshooting Guide for Intel® S5500/S3420 series Server Boards
70
Intel order number G74211-001
Revision 1.0
Table 69: System Event Sensor Typical Characteristics
Byte
Field
Description
8
9
Generator ID
0001h = BIOS POST
0033h = BIOS SMI Handler
11
Sensor Type
12h = System Event
12
Sensor Number
83h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14
Event Data 1
[7:6]
– 00b = Unspecified Event Data 2
[5:4]
– 00b = Unspecified Event Data 3
[3:0]
– Event Trigger Offset
01h = System Boot
05h = Timestamp Clock Synchronization
15
Event Data 2
For Event Trigger Offset 05h only (Timestamp Clock
Synchronization)
00h = 1st in pair
80h = 2nd in pair
16
Event Data 3
Not Used.
