System Event Log Troubleshooting Guide for Intel ® S5500/S3420 series Server Boards PCI Express and Legacy PCI subsystem
Revision 1.0 Intel order number G74211-001 67
Event Trigger Offset
Description Next Steps
Hex Description
0Dh Received ERR_NONFATAL Message Error Indicates a non-fatal error is redefined as fatal, and is being
reported.
10.1.3 Legacy PCI Errors
Legacy PCI errors include PERR and SERR, both are fatal errors.
Table 67: Legacy PCI Error Sensor Typical Characteristics
Byte Field Description
8
9
Generator ID 0033h = BIOS SMI Handler
11 Sensor Type 13h = Critical Interrupt
12 Sensor Number 03h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 6Fh (Sensor Specific)
14 Event Data 1
[7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Event Trigger Offset as described in Table 68
15 Event Data 2 PCI Bus number
16 Event Data 3
[7:3] – PCI Device number
[2:0] – PCI Function number
